![Front View-LCN101A](//cdn.shopify.com/s/files/1/0047/6764/5770/files/Front_View-LCN101A_1024x1024.jpg?v=1551062515)
![Time Switch Application Scene](//cdn.shopify.com/s/files/1/0047/6764/5770/files/Time_Switch_Application_Scene_1024x1024.jpg?v=1550668737)
Type |
LCN101A |
Working Voltage |
100,110,115,120,127VAC |
220,230,240VAC |
12,24,36VDC |
Resistance Load Switch Capacity |
16A |
25A |
16A |
Power Consumption |
<1W |
<2W |
<1W |
Voltage Range |
85~110% |
Power Source Frequency |
50/60HZ |
Power Reserve Time |
5 Years |
Control Electrical Life |
100000 Times |
Mechanical Life |
10000000 Times |
Display |
LCD |
Setting Switch |
16 Times Open And 16 Times Off |
Timing Control Range |
1 min- 168 hours |
Average Error |
<±0.5s/24h,25℃ |
Mini Interval |
1 min |
Temperature |
-25℃~ +60℃ |
Relative Humidity |
<95% |
Weight |
65g |
Dimensions |
60*60*32mm |
Installation |
Screw Fixation & Panel |
Shell Material |
PC Material, Proof Flame |
![Dimension-LCN101A](//cdn.shopify.com/s/files/1/0047/6764/5770/files/Dimension-LCN101A_1024x1024.jpg?v=1551062675)
![Detail-LCN101A](//cdn.shopify.com/s/files/1/0047/6764/5770/files/Detail-LCN101A_1024x1024.jpg?v=1551062712)
![Structure-LCN101A](//cdn.shopify.com/s/files/1/0047/6764/5770/files/Structure-LCN101A_1024x1024.jpg?v=1551062741)
