Classification |
Amperemeter & Voltmeter |
Model |
LDP3-AA |
LDP3-AV |
Max. Display |
1999(AC display valid value) |
Input mode Single input |
(Less than 700V for AC Voltmeter) |
A/D conversion |
Double intergral |
Measuring Speed |
2.5times/S |
Frequency Range |
40~200Hz( only for AC) |
Overflow Display |
"1" or "-1" |
Polarity Display |
only "-" (just for DC) |
Display |
0.80 inch Red(color:Green, Yellow, Blue) |
Power |
110/220VAC |
Comsuption |
≤4.5VA |
Accuracy |
0.5%FS±1 |
Dielectric Strength |
AC1500V / M (Between Power and external terminals) |
![Dimensions and Connecting Diagram-LDP3](//cdn.shopify.com/s/files/1/0047/6764/5770/files/Dimensions_and_Connecting_Diagram-LDP3.jpg?v=1557902710)
![Model Number Structure-LDP3](//cdn.shopify.com/s/files/1/0047/6764/5770/files/Model_Number_Structure-LDP3_1024x1024.jpg?v=1557903008)
